TS8223K SPDT 10W/50Wp RF GaN Switch
Features
Frequency Range 500MHz to 8.5GHz
Low insertion loss:
- 0.30dB @ 2.0GHz
- 0.30dB @ 4.0GHz
- 0.40dB @ 6.0GHz
- 0.55dB @ 8.5GHz
High isolation:
- 40dB @ 2.0GHz
- 35dB @ 4.0GHz
- 27dB @ 6.0GHz
- 22dB @ 8.5GHz
10W CW Power, 50Wp Peak Power
Low power consumption, less than 1mW
Switching time 200ns
P0.1dB compression point tbd dBm
H2, Pin=40dBm, 800MHz, tbd dBc
H3, Pin=40dBm, 800MHz, tbd dBc
